适合房车的创新堆肥马桶美洁活灵思维导图

U372710416

2024-07-23

浏览量: 108

产品介绍

产品说明

功能特点

卫浴产品功能特点内容讲解

树图思维导图提供《适合房车的创新堆肥马桶美洁活灵》在线思维导图免费制作，点击“编辑”按钮，可对《适合房车的创新堆肥马桶美洁活灵》进行在线思维导图编辑，本思维导图属于思维导图模板主题，文件编号是：10e0d7f51331cbfa46cb78d692fa535d

思维导图大纲

功能特点 Features

智能马桶盖 Smart Toilet Seat

可选配功能：可配备有冲水功能的智能马桶盖。Equipped with a smart toilet seat that includes a flushing function

无需外部电源：使用车内的冷热水供给。 It uses the RV's hot and cold water supply without needing an external power source

高效去污 Efficient Cleaning

可以使用水清洗马桶周围的污垢，而不会有清洗水进入废物处理仓。When cleaning the toilet, you can use water to clean around the toilet without any cleaning water entering the waste treatment compartment.

快速废物处理 Rapid Waste Processing

新鲜的大便进入废物处理仓后：只需10分钟就会消失。Fresh feces enter the waste treatment compartment and disappear in just 10 minutes.

处理后的废物不会附着在手上：没有任何气味。The processed waste does not stick to your hands and is odor-free.

紧凑且多功能 Compact and Multifunctional

结合优点：这款房车堆肥马桶结合了传统堆肥马桶和抽拉式马桶的优点。This RV composting toilet combines the benefits of traditional composting toilets and cassette toilets.

应用环境：它配备了可旋转的底座：适应各种安装环境：体积更小：更适合狭小空间。It features a rotating seat ring to adapt to various installation environments, making it more suitable for tight spaces.

便携抽拉系统 Convenient Cassette System

特点：马桶配备了类似于传统汽车马桶的抽拉式容器。The toilet is equipped with a waste cassette similar to traditional RV toilets.

使用方便：这样，在更换马桶时无需对车厢进行清扫：抽拉箱的尺寸与传统车厢门相匹配：能够顺利出入：无需额外装载车辆。This means you can replace the toilet without modifying the RV cabin. The cassette's size matches the traditional RV compartment door, allowing it to move in and out smoothly without additional vehicle modifications.

紧凑尺寸 Compact Dimensions

尺寸规格：马桶尺寸为55厘米长、37厘米宽、46.5厘米坐高。The toilet measures 55 cm in length, 37 cm in width, and 46.5 cm in seat height, perfectly fitting the tight spaces of an RV.

安装需求：完全符合房车狭小空间的安装要求：宽度和坐高几乎与市场上流行的抽拉马桶相同：长度比传统型号短了2厘米。The width and seat height are almost the same as popular cassette toilets on the market, and the length is 2 cm shorter than traditional models.

多样电源选项 Multiple Power Options

低压直压电：马桶采用低压直流电（12V、24V或48V）供电。The toilet is powered by low-voltage DC (12V, 24V, or 48V), making it safer.

更加安全：如果家中使用：可以增加适配器：连接到交流插座上。For home use, you can add an adapter to connect it to an AC outlet.

耐用使用 Durable Use

根据情况：根据使用情况：两人每日使用的状况下：马桶可以持续一个月使用：如果是单人使用：则可用两个月。8.Depending on usage, the toilet can be used for one month by two people using it daily; if used by one person, it can last for two months.

无异味堆肥处理 Odor-Free Composting

去除异味：采用好氧处理技术：将废物分解为二氧化碳和水：处理过程快速：无异味产生。Using aerobic treatment technology, it effectively removes odors, decomposes waste into carbon dioxide and water, and the treatment process is fast and odor-free.

安静运行 Quiet Operation

先进的技术：马桶配备了先进的隔音控制技术。两种模式：有两种模式：一是根据环境噪音调整风机噪音：另一种是根据日常睡眠时间控制噪音：确保在安静的环境中或睡眠时运行安静。The toilet is equipped with advanced noise control technology with two modes: one adjusts fan noise according to ambient noise, and the other controls noise according to daily sleep times, ensuring quiet operation in a quiet environment or during sleep.

分开处理废物 Separate Waste Processing

收集方式：与传统堆肥马桶一样：本款马桶采用大小便分开收集的方式。Like traditional composting toilets, this toilet adopts a separate collection system for urine and feces.

后期处理：可以单独处理后排泄物：或添加加速化学分解剂后与灰水混合排放。Urine can be treated separately and discharged, or mixed with greywater after adding non-chemical deodorants.

除湿功能 Dehumidification

提升效果：马桶配备了除湿功能：可在废物处理仓湿度过高时自动启动：提升处理效果。The toilet features a dehumidification function that activates when the humidity in the waste treatment compartment is too high, enhancing the treatment effect.

自动恒温功能 Automatic Temperature Control

具备低温自动恒温功能，当环境温度低于5°C时，会自动启用恒温功能，确保最佳工作条件。With low-temperature automatic temperature control, the system activates when the ambient temperature drops below 5°C, ensuring optimal working conditions.

高效搅拌 Efficient Mixing

双轴对称搅拌机构能够将卫生纸撕成碎末，解决了处理卫生纸的问题。The dual-axis symmetrical mixing mechanism can shred toilet paper into fine particles, solving the problem of handling toilet paper.

智能搅拌系统 Intelligent Mixing System

配备了智能化程序控制的自动搅拌系统，全程无需人工干预，确保物料搅拌充分，优化堆肥反应，延长清理间隔时间。Unlike traditional RV composting toilets, this model is equipped with an intelligent program-controlled automatic mixing system, requiring no manual intervention, ensuring thorough material mixing, optimizing the composting reaction, and extending cleaning intervals.
